NPB-750-24
24Vdc 22.5A Battery Charger IntelligentManufacturer: MEAN WELL
View Data Sheet
In Stock: 109 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$227.24
5
$216.43
10
$206.89
20
$200.91
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
90~264Vac
Output Charge Voltage:
28.8Vdc
Max Charge Current:
22.5 Amps
Max Power:
756 Watts
Features
AC input range: 90~264Vac
Operating temperature range: -30~+70°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Built-in PFC
Charger OK signal
Battery full signal
Built-in fan with fan speed control
LED indicator for charging status
User selectable charging: 2 or 3 stage charging mode
AC inlet: IEC 320-C14
Output connector: Terminal block
On/Off switch
Built-in remote On/Off
Programmable output voltage and output current
Output current adjustable via potentiometers
Protections: battery reverse polarity / battery under voltage / short circuit / over temperature / overvoltage
MEAN WELL 3 year warranty
