LDH-45A-500W
I/P 9~18VDC 4.1A O/P 12~86VDC 500mA Constant Current DC/DC, WireManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$14.38
10
$12.32
20
$11.98
100
$11.50
200
$11.35
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~18Vdc
Constant Current:
500 mA
Constant Current Operating Range:
12~86 Vdc
Max Power:
43 Watts
Features
Input range: 9~18Vdc
Operating case temperature: -40~+70°C
Built-in EMI filter complies with EN55015 without additional input filter and capacitors
Constant current design
Fully encapsulated compact size
Wire style package
High Efficiency
Built-in PWM plus analog dimming and remote On/Off control
Protections: short circuit / over voltage / under voltage
MEAN WELL 3 year warranty
LDH-45A-500W
I/P 9~18VDC 4.1A O/P 12~86VDC 500mA Constant Current DC/DC, WireManufacturer: MEAN WELL
View Data Sheet
Specifications
Input Voltage:
9~18Vdc
Constant Current:
500 mA
Constant Current Operating Range:
12~86 Vdc
Max Power:
43 Watts
Features
Input range: 9~18Vdc
Operating case temperature: -40~+70°C
Built-in EMI filter complies with EN55015 without additional input filter and capacitors
Constant current design
Fully encapsulated compact size
Wire style package
High Efficiency
Built-in PWM plus analog dimming and remote On/Off control
Protections: short circuit / over voltage / under voltage
MEAN WELL 3 year warranty
