TIM 6-1223
15V,-15V, Medical DC/DC Converter, Wide 2:1 Input Range, DIP-24 PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
9~18Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.2 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-0.2 Amps
Max Power:
6 Watts
Features
DIP-24 package medical DC/DC converter
Wide 2:1 input voltage range
Operating temperature range: -40~+95°C
Medical safety certification: ANSI/AAMI ES/IEC/EN 60601-1
2xMOPP
EMC emission compliant to EN 60601-1-2 4th edition
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Low leakage current/touch current ≤2µA
MIL-STD-810F: vibration, mechanical/thermal shock
I/O isolation: 5000Vac
Regulated output
Meets EN 55032 class B with external filter
Operation up to 5000m altitude
Under-voltage lock out circuit
Protections: short circuit / overvoltage
TRACO Power 5 year warranty
