THN 15-4825N
Dual O/P, DC/DC Converter 1x1 Inch, Dual Output Wide 2:1 Input Voltage RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
36~75Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.5 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-0.5 Amps
Max Power:
15 Watts
Features
TRACO Power THN 15-4825N compact 1x1 inch DC/DC converter
Wide 2:1 input voltage ranges
Operating temperature: -40~+105°C (with derating)
Safety approvals: UL/EN/IEC 62368-1
Low no load power consumption
Industry standard pinout
Shielded metal case with insulated baseplate
I/O isolation 1600Vdc
Output voltage trim
Remote On/Off
Protections: over load / short circuit / over voltage
TRACO Power 3 year warranty
