DDRH-15-05P
I/P:150~1500VDC; O/P:5V/0~2A DC/DC Converter, PCB Mount TypeManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
150~1500Vdc
Output Voltage:
5Vdc
Output Max Current:
2 Amps
Max Power:
15 Watts
Features
Compact PCB mount DC/DC converter
Ultra-wide 10:1 input range
Operating temperature range: -40~+80°C
Industrial safety certification: IEC 62109-1
I/O isolation: 4000Vdc
Operation up to 5000m altitude
Overvoltage Category II
Protections: short circuit / overload / over voltage / DC input under voltage / DC input reverse polarity
MEAN WELL 3 year warranty
DDRH-15-05P
I/P:150~1500VDC; O/P:5V/0~2A DC/DC Converter, PCB Mount TypeManufacturer: MEAN WELL
View Data Sheet
Specifications
Input Voltage:
150~1500Vdc
Output Voltage:
5Vdc
Output Max Current:
2 Amps
Max Power:
15 Watts
Features
Compact PCB mount DC/DC converter
Ultra-wide 10:1 input range
Operating temperature range: -40~+80°C
Industrial safety certification: IEC 62109-1
I/O isolation: 4000Vdc
Operation up to 5000m altitude
Overvoltage Category II
Protections: short circuit / overload / over voltage / DC input under voltage / DC input reverse polarity
MEAN WELL 3 year warranty
