DRS-240-24
24Vdc 10A +24Vdc 7.7A 24V DIN Rail Power Supply Battery Charger Output UPS FunctionManufacturer: MEAN WELL
View Data Sheet
In Stock: 71 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$218.50
5
$208.15
10
$198.95
20
$193.20
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
90~305Vac
Output Voltage:
24Vdc
Output Max Current:
10 Amps
Max Power:
240 Watts
Features
AC input range: 90~305Vac
Operating temperature range: -30~+70°C
Industrial safety certification: EN 62368-1, UL 62368-1
User selectable charging: 2 or 3 stage charging mode
Built-in PFC
Adjustable charging current (adjustable by VR)
LED indicator and output relays for DC OK, charging status, AC FAIL, battery low, and charger failure
Built-in MODBus
Withstands 5G vibration
Can be installed on DIN Rail TS-35/7.5 or TS-35/15
Overvoltage category III
Protections: short circuit / overload / reverse polarity / over temperature / over voltage / battery cut off
MEAN WELL 3 year warranty
