DRA-40-24
24Vdc 1.7A, 24V Din Rail Power Supply Operates: CV or CC DimmableManufacturer: MEAN WELL
View Data Sheet
In Stock: 13 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~264Vac
Output Voltage (CV mode):
24Vdc
Output Max Current (CV mode):
1.7 Amps
Output Current (CC mode):
1.7 Amps
Constant Current Operating Range:
3~24Vdc
Max Power:
40 Watts
Features
AC input range: 90~264Vac
Operating temperature range: -30~+70°C
UL60950-1 Safety Approval
Operates in constant voltage or constant current mode
Current adjustable through external: 1~10Vdc, PWM signal or resistance signal
Output voltage adjustable via internal potentiometer
High efficiency
Pass LPS
Installed on DIN rail TS35 / 7.5 or 15
LED indicator for power on
Protections: short circuit / over load / over voltage
MEAN WELL 3 year warranty
DRA-40-24
24Vdc 1.7A, 24V Din Rail Power Supply Operates: CV or CC DimmableManufacturer: MEAN WELL
View Data Sheet
Specifications
Input Voltage:
90~264Vac
Output Voltage (CV mode):
24Vdc
Output Max Current (CV mode):
1.7 Amps
Output Current (CC mode):
1.7 Amps
Constant Current Operating Range:
3~24Vdc
Max Power:
40 Watts
Features
AC input range: 90~264Vac
Operating temperature range: -30~+70°C
UL60950-1 Safety Approval
Operates in constant voltage or constant current mode
Current adjustable through external: 1~10Vdc, PWM signal or resistance signal
Output voltage adjustable via internal potentiometer
High efficiency
Pass LPS
Installed on DIN rail TS35 / 7.5 or 15
LED indicator for power on
Protections: short circuit / over load / over voltage
MEAN WELL 3 year warranty
