HLG-320H-48A
48Vdc 6.7A LED Driver, IP65, PFC Harsh Environment, Metal Case 48V 6.7AManufacturer: MEAN WELL
View Data Sheet
In Stock: 193 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
90~305Vac
Output Voltage (CV mode):
48Vdc
Output Max Current (CV mode):
6.7 Amps
Output Current (CC mode):
6.7 Amps
Constant Current Operating Range:
24~48Vdc
Max Power:
321 Watts
Features
Full range AC input: 90~305Vac
Operating case temperature: -40~+90°C
UL8750 type HL LED power supply
Meet 4kV surge immunity level (IEC61000-4-5)
Built-in active PFC
IP65 durable aluminium enclosure
High efficiency
Output voltage and constant current level can be adjusted through internal potentiometers
Protections: short circuit / over current / over voltage / over temperature
Applications: LED electric display, lighting, LED street lighting and indoor/outdoor lighting
MEAN WELL 7 year warranty
