LPF-16-24

24V 0.67A 24Vdc LED Driver IP30, Class II, Class 2, PFC 24V 0.67A

Manufacturer: MEAN WELL

View Data Sheet

In Stock: 372 can ship immediately

i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.

Lead time for quantities greater than shown, contact us

*The import tariff is included in the unit price

Quantity
Unit Price
1
$23.58
5
$22.43
10
$21.51
20
$20.82

Specifications

Input Voltage:

90~305Vac

Output Voltage (CV mode):

24Vdc

Output Max Current (CV mode):

0.67 Amps

Output Current (CC mode):

0.67 Amps

Constant Current Operating Range:

13.2~24Vdc

Max Power:

16 Watts

Features

Full range AC input: 90~305Vac

Operating temperature range: -35~+70°C

UL8750 LED Power Supply, Class 2

Class II AC input (two wires-no FG connection)

Built-in active PFC

Fully insulated plastic case with 94V-0 fire prevention level

High efficiency

IP30

Protections: short circuit / over current / over voltage / over temperature

MEAN WELL 5 year warranty

MEAN WELL LPF-16-24

LPF-16-24

24V 0.67A 24Vdc LED Driver IP30, Class II, Class 2, PFC 24V 0.67A

Manufacturer: MEAN WELL

View Data Sheet

Specifications

Input Voltage:

90~305Vac

Output Voltage (CV mode):

24Vdc

Output Max Current (CV mode):

0.67 Amps

Output Current (CC mode):

0.67 Amps

Constant Current Operating Range:

13.2~24Vdc

Max Power:

16 Watts

Features

Full range AC input: 90~305Vac

Operating temperature range: -35~+70°C

UL8750 LED Power Supply, Class 2

Class II AC input (two wires-no FG connection)

Built-in active PFC

Fully insulated plastic case with 94V-0 fire prevention level

High efficiency

IP30

Protections: short circuit / over current / over voltage / over temperature

MEAN WELL 5 year warranty
