RSP-150-48
48Vdc /3.2A, 48Volts Power Supply Low Profile, PFC 48V 3.2A, 150 WattsManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
48Vdc
Output Max Current:
3.2 Amps
Max Power:
153 Watts
Features
Universal AC input range: 85~264vac
Operating temperature range: -30~+70°C
Safety approvals: UL 62368-1 & TUV EN 62368-1-1
30mm low profile design for 1U installation
Fan-less design, cooling by free air convection
Built-in constant current limiting circuit
Remote On/Off control
LED indicator for power on
Protections: short circuit / over load / over voltage / over temperature / over voltage category III
MEAN WELL 3 year warranty
