EPS-120-24

24Vdc 5A 24Vdc AC/DC Power Supply Single Output, 4"x2" 24V 5Amps

Manufacturer: MEAN WELL

View Data Sheet

In Stock: 279 can ship immediately

i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.

Lead time for quantities greater than shown, contact us

*The import tariff is included in the unit price

Quantity
Unit Price
1
$24.50
5
$23.35
10
$22.31
20
$21.62

Specifications

Input Voltage:

80~264Vac

Output Voltage:

24Vdc

Output Max Current:

5 Amps

Max Power:

120 Watts

Features

AC input range: 80~264Vac

Operating temperature: -30~+70°C

Safety standard: UL62368-1

No load power consumption <0.3W

EMI Class B for both Class I (with FG) and Class II (without FG) configuration

2x4" open frame power supply

LED indicator for power On

Built-in 12V/0.5A fan supply

Cooling by free air convection for 84W and 120W with 10CFM forced air

Protections: short circuit / over load / over voltage / over temperature

MEAN WELL 3 year warranty

MEAN WELL EPS-120-24

EPS-120-24

24Vdc 5A 24Vdc AC/DC Power Supply Single Output, 4"x2" 24V 5Amps

Manufacturer: MEAN WELL

View Data Sheet

Specifications

Input Voltage:

80~264Vac

Output Voltage:

24Vdc

Output Max Current:

5 Amps

Max Power:

120 Watts

Features

AC input range: 80~264Vac

Operating temperature: -30~+70°C

Safety standard: UL62368-1

No load power consumption <0.3W

EMI Class B for both Class I (with FG) and Class II (without FG) configuration

2x4" open frame power supply

LED indicator for power On

Built-in 12V/0.5A fan supply

Cooling by free air convection for 84W and 120W with 10CFM forced air

Protections: short circuit / over load / over voltage / over temperature

MEAN WELL 3 year warranty

In Stock: 279 can ship immediately

i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.

Lead time for quantities greater than shown, contact us

*The import tariff is included in the unit price

Quantity
Unit Price
1
$24.50
5
$23.35
10
$22.31
20
$21.62
