LD03-23B12R2
12 Volt Power Supply PCB Mount 12 Volts 0.25 AmpsManufacturer: Mornsun
View Data Sheet
In Stock: 200 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~305Vac
Output Voltage:
12Vdc
Output Max Current:
0.25 Amps
Max Power:
3 Watts
Features
MORNSUN LD03-23B12R2 1x1 inches encapsulated on-board type power supply
AC input range: 85~305Vac
Operating temperature range: -40~+85°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
No load power consumption ≤0.1 Watt
Operation up to 5000m altitude
Optional DIN Rail mounting available
Protections: short circuit / overcurrent / overvoltage
Mornsun 3 year warranty
