Manufacturer: XP Power
View Data Sheet
Availability: Contact Us
Lead time for quantities greater than shown, contact us
REQUEST a QUOTE for higher qty discounts
Input Voltage:
9~18Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.125 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.125 Amps
Max Power:
3 Watts
XP Power JCB0312D12 Compact DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+100°C
Input filter meets EN 55022 class A
I/O isolation: 1500Vdc
Fully regulated output
Protections: undervoltage-lockout / reverse voltage / short circuit / overvoltage / overcurrent
XP Power 3 year warranty
