TRV 2-1211M
5Vdc 0.4A, Medical DC/DC Converter SIP-9 Package, 2xMOPPManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$19.10
10
$16.95
25
$16.29
100
$15.21
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9.6~14.4Vdc
Output Voltage:
5Vdc
Output Max Current:
0.4 Amps
Max Power:
2 Watts
Features
TRACO Power TRV 02-1211M SIP package medical DC/DC converter
Wide 1.5:1 input range
Operating temperature range: -40~+80°C
Medical safety certification: ANSI/AAMI ES/IEC/EN 60601-1
EMC emission compliant to EN 60601-1-2 4th edition
2xMOPP
Low leakage current/touch current ≤2µA
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
I/O isolation: 5000Vac
MIL-STD-810F: vibration, mechanical/thermal shock
Meets EN 55032 class B with external filter
Regulated output
Operation up to 5000m altitude
Protections: short circuit
TRACO Power 5 year warranty
