THP 3-4823
Dual O/P, Medical DC-DC Converter DIL-24 PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~80Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.1 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
0.1 Amps
Max Power:
3 Watts
Features
TRACO Power THP 3-4823 low profile DIL-24 package medical DC/DC converter
Operating temperature: -40~+85°C
Medical safety approvals: UL 60601-1 & IEC/EN 60601-1 3rd edition
2xMOOP (means of operator protection)
Industrial safety approvals: UL/IEC/EN 60950-1
Supplementary and reinforced insulation
I/O isolation 3000Vacrms rated for 300 Vrms working voltage
Input filter meets EN55022, class A without external components
Continuous short circuit protection
TRACO Power 3 years warranty
