THN 20-2415WI
24Vdc 0.833A, DC/DC Converter 1x1 Inch Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
9~36Vdc
Output Voltage:
24Vdc
Output Max Current:
0.833 Amps
Max Power:
19.99 Watts
Features
TRACO Power THN 20-2415WI compact 1x1 encapsulated on board DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+75°C (up to +85°C with optional heat sink)
Safety approvals: UL/EN/IEC 60950-1
I/O isolation 1500Vdc
Adjustable output voltage
No minimum load required
Shielded metal case with isolated baseplate
Input filter meets EN 55022 class A without external components
Remote On/Off
Protections: short circuit / over voltage
TRACO Power 3 year warranty
THN 20-2415WI
24Vdc 0.833A, DC/DC Converter 1x1 Inch Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
9~36Vdc
Output Voltage:
24Vdc
Output Max Current:
0.833 Amps
Max Power:
19.99 Watts
Features
TRACO Power THN 20-2415WI compact 1x1 encapsulated on board DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+75°C (up to +85°C with optional heat sink)
Safety approvals: UL/EN/IEC 60950-1
I/O isolation 1500Vdc
Adjustable output voltage
No minimum load required
Shielded metal case with isolated baseplate
Input filter meets EN 55022 class A without external components
Remote On/Off
Protections: short circuit / over voltage
TRACO Power 3 year warranty
