Power Worth Searching For
THL 30-4823WI
Dual O/P, Regulated DC/DC Converter 1x1 Metal Package 4:1 Input, Remote On/Off, TrimManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
1 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-1 Amps
Max Power:
30 Watts
Features
TRACO Power THL 30-4823WI 1x1 inches DC/DC converter
Ultra-wide 4:1 input range
Operating temperature range: -40~+80°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
I/O isolation: 1500Vac
Built-in remote On/Off
Trim function
No minimum load required
Operation up to 6000m altitude
Under voltage lock-out circuit
Protections: short circuit / overvoltage / overload
Optional heastsink
TRACO Power 3 year warranty
