THL 25-4823
Dual O/P, DC-DC Converter 1x1 Package Wide 2:1 Input Voltage RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
36~75Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
1.04 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
1.04 Amps
Max Power:
25 Watts
Features
TRACO Power THL 25-4823 high power density 1x1 DC/DC converter
Wide 2:1 input voltage ranges
Operating temperature: -40~+80°C (up to +85°C with optional heat-sink)
I/O isolation 1500Vdc
Ultra-compact size: 1.0x1.0x0.4 inch
Shielded metal case with isolated baseplate
High efficiency
Adjustable output voltage
Optional heat-sink available
Remote On/Off
Protections: short circuit / over voltage
TRACO Power 3 year warranty
