THL 10-2421
Dual O/P, DC-DC Converter 1x1 Package 2:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~36Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
1 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
1 Amps
Max Power:
10 Watts
Features
TRACO Power THL 10-2421 1x1 package DC/DC converter
Wide 2:1 input voltage range
Operating temperature: -40~+80°C (up to +85°C with optional heat-sink)
Shielded metal case with isolated baseplate
I/O isolation 1500Vdc
Input filter meets EN 55022 class A without external components
Optional heat-sink available
Industry standard pinout
Short circuit protection
TRACO Power 3 year warranty
