THL 10-1213
15Vdc 0.67A, DC-DC Converter 1x1 Package 2:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
9~18Vdc
Output Voltage:
15Vdc
Output Max Current:
0.67 Amps
Max Power:
10 Watts
Features
TRACO Power THL 10-1213 1x1 package DC/DC converter
Wide 2:1 input voltage range
Operating temperature: -40~+80°C (up to +85°C with optional heat-sink)
Shielded metal case with isolated baseplate
I/O isolation 1500Vdc
Input filter meets EN 55022 class A without external components
Optional heat-sink available
Industry standard pinout
Short circuit protection
TRACO Power 3 year warranty
