Power Worth Searching For
TEN 20-4821WIN
Dual O/P, DC-DC Converter 2x1 Package Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
2 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
-2 Amps
Max Power:
20 Watts
Features
TRACO Power TEN 20-4821WIN high power density 2x1 metal package
Ultra wide 4:1 input range
Operating temperature: -40~+85°C
I/O isolation 1500Vdc
No minimum load required
Adjustable output voltage
Shielded metal case with insulated baseplate
Remote On/Off
Optional heat sink available
Protections: short circuit / over load / over voltage
TRACO Power 3 year warranty
TEN 20-4821WIN
Dual O/P, DC-DC Converter 2x1 Package Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
2 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
-2 Amps
Max Power:
20 Watts
Features
TRACO Power TEN 20-4821WIN high power density 2x1 metal package
Ultra wide 4:1 input range
Operating temperature: -40~+85°C
I/O isolation 1500Vdc
No minimum load required
Adjustable output voltage
Shielded metal case with insulated baseplate
Remote On/Off
Optional heat sink available
Protections: short circuit / over load / over voltage
TRACO Power 3 year warranty
