Power Worth Searching For
TEL 15-4811N
5.1Vdc 2.94A, DC/DC Converter DIP Metal Package 2:1 InputManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
36~75Vdc
Output Voltage:
5.1Vdc
Output Max Current:
2.94 Amps
Max Power:
15 Watts
Features
TRACO Power TEL 15-4811N DIP-16 metal package DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+80°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
I/O isolation: 1500Vac
No minimum load required
Operation up to 6000m altitude
Under voltage lock-out circuit
Protections: short circuit (continuous, automatic recovery)
TRACO Power 3 year warranty
TEL 15-4811N
5.1Vdc 2.94A, DC/DC Converter DIP Metal Package 2:1 InputManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
36~75Vdc
Output Voltage:
5.1Vdc
Output Max Current:
2.94 Amps
Max Power:
15 Watts
Features
TRACO Power TEL 15-4811N DIP-16 metal package DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+80°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
I/O isolation: 1500Vac
No minimum load required
Operation up to 6000m altitude
Under voltage lock-out circuit
Protections: short circuit (continuous, automatic recovery)
TRACO Power 3 year warranty
