TEL 15-4810
3.3Vdc 3A, DC-DC Converter 2x1 PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
36~75Vdc
Output Voltage:
3.3Vdc
Output Max Current:
3 Amps
Max Power:
15 Watts
Features
TRACO Power TEL 15-4810 compact 2x1 inches DC/DC converter
Wide 2:1 input voltage range
Operating temperature: -40~+80°C
I/O isolation 1500Vdc
High efficiency
Industry standard pinout
Cost optimized design
Optional heat sink
Short circuit protection
TRACO Power 3 year warranty
