TEL 12-4823
Dual O/P, DC/DC Converter DIP-16 Package 2:1 InputManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
36~75Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.5 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
0.5 Amps
Max Power:
12 Watts
Features
TRACO Power TEL 12-4823 compact DIP-package design DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+85°C
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Input filter meets EN 55032 class A
I/O isolation 1500Vdc
Fully regulated output
Protections: short circuit
TRACO Power 3 year warranty
