THN 30-4822WI
Dual O/P, DC/DC Converter 1x1 Inch Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
In Stock: 2 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
1.25 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
1.25 Amps
Max Power:
30 Watts
Features
TRACO Power THN 30-4822WI compact 1x1 encapsulated on board DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+80°C (up to 85°C with heat sink)
Safety approvals: UL/EN/IEC 60950-1
I/O isolation 1500Vdc
Adjustable output voltage
No minimum load required
Shielded metal case with isolated baseplate
Remote On/Off
Protections: short circuit / over voltage /over temperature
TRACO Power 3 year warranty
